- Heavy-Duty Construction: provides extra strength and durability
- Open Architecture: provides increased ventilation and easier access to wires
- Slim Design: provides a low profile
- Automatic Spring Locks with Quick Release Cords: allow TV removal quick and easy
- Integrated Bubble Level: assures alignment
Sesigned for modern aesthetics and maximum functionality, this wall mount provides a sleek and sturdy solution for securely mounting large-screen TVs to the wall. The slim design aligns the TV seamlessly to the wall. Simple construction makes installation quick and easy. Automatic spring lock helps TV mount snap into place for added security.
Dimensions: 24x438x425 mm
Fit Screen Size: 32"-75"
Fit Curved TV: Yes
Mounting Hole Pattern: VESA & Universal
VESA Compatible: 50x50, 75x75, 100x100, 100x150, 150x100, 100x200, 200x100, 150x150, 200x200, 200x300, 300x200, 200x400, 400x200, 300x300, 300x400, 400x300, 400x400
Max. Mounting Hole: 410x402
Weight Capacity: 75kg
Strength Tested: 4 Times Approved
Profile: 24 mm
Installation: Solid Wall,Double Stud(406mm)
Panel Type: Detachable Panel
Wall Plate Type: Fixed Wall Plate
AV Component Shelf: No
Direction Indicator: No
Cable Management: No
Anti-theft: No
Bubble Level: Built-in Bubble Level (Integrated on Wall Plate/VESA Panel)
General
- Farge
- Svart
Functions
- Height adjustable
- Nei
- Side adjustment
- Nei
- Dybde justering
- Nei
- Tiltable
- Nei
- Swing/Pan
- Nei
- Roll/Pivot
- Nei
- Motorized
- Nei
- Lockable
- Nei
Montering
- Number of displays
- 1 pcs.
- Weight capacity (per screen)
- 75 kg
- Monteringsmetode
- Wall
- VESA mount interface (mm)
- 100x100, 100x150, 100x200, 200x100, 200x200, 200x300, 200x400, 300x200, 300x300, 300x400, 400x200, 400x300, 400x400, 50x50
Størrelse & Vekt
- Width
- 438 mm
- Høyde
- 425 mm
- Dypde
- 24 mm
Pakkeinformasjon
- Pakkestørrelse
- 451 x 159 x 35 mm
- Pakkevekt
- 1,53 kg
