The POE90U1BT Single Port PoE Injector from Pelco is designed to meet the data rate and power requirements of IP cameras with high-quality streaming video capabilities. It provides total power output of 90W, which meets the IEEE 802.3bt standard for detection, connection, disconnection, and fault protection. It is compatible with 10/100/1000Base-T systems. This injector supports AC input voltage of 100 to 240 VAC ± 10% and an input frequency of 47 to 63 Hz. The maximum output load current is 1.6A at 56 VDC.
Features:
- Diagnostic LEDs
- Broken wire detection
- Overcurrent and overvoltage protection
- The output can be shorted permanently without damage
- Power cord required for operation (available separately)
- Ethernet (RJ-45)
- Ja
Nettverk
- Dataoverføringshastighet
- 1 Gbit/s
- Antall LAN-tilkoblinger (RJ-45)
- 2 pcs.
- Antall LAN-innganger (RJ-45)
- 1 pcs.
- Antall LAN-utganger (RJ-45)
- 1 pcs.
Electrical specifications
- Maximum Power
- 90 W
- PoE Standard
- IEEE 802.3bt Type 4 (PoE++)
Mål og vekt
- Width
- 80 mm
- Dypde
- 166 mm
- Høyde
- 44 mm
- Net weight
- 0,5 kg
Pakkeinformasjon
- Pakkestørrelse
- 219 x 152 x 65 mm
- Pakkevekt
- 757 g
- Strekkode
- 700880440346
